Flashing / Back Channel / Flatsheet

New
Compare
SKU: Flashing/BackChannel/Flatsheet Category:

Technical specifications

Ridge Capping

Available in 3M & 6M lengths.
Clear, Bronze or Grey Polycarbonate.

FLASHING Ridge Capping
Apron Flashing

Available in 3M & 6M lengths.
Clear, Bronze or Grey Polycarbonate.

FLASHING Apron Flashing

Barge Capping

Available in 3M & 6M lengths.
Clear, Bronze or Grey Polycarbonate.

FLASHING Barge Capping

Back Channel Flashing

Alsynite One recommend you use this in conjunction with Back Channel Infill Strip Foam.

FLASHING Back ch Flashing Roma Greca



Polycarbonate Flashings 3M & 6M (Clear, Bronze or Grey)
Apron Flashing 110 x 130 x 10mm (90deg) 3M
Apron Flashing 110 x 130 x 10mm (90deg) 6M
Apron Flashing 60 x 70 x 20mm (90deg) 3M
Apron Flashing 60 x 70 x 20mm (90deg) 6M
Barge Flashing 70 x 60 x 20mm (90deg) 3M
Barge Flashing 70 x 60 x 20mm (90deg) 6M
Barge Flashing 90 x 130 x 20mm (90deg) 3M
Barge Flashing 90 x 130 x 20mm (90deg) 6M
Ridge Capping 110 x 110 (25deg) x 3M (wide)
Ridge Capping 110 x 110 (25deg) x 6M (wide)
Ridge Capping 110 x 110 (45deg) x 3M (Narrow)
Ridge Capping 110 x 110 (45deg) x 6M (Narrow)
Ridge Capping 10 x 115 x 115 x 10mm (120deg) x 3M
Ridge Capping 10 x 115 x 115 x 10mm (120deg) x 6M
Valley Flashing 15 x 25 x135 x135 x25 x 15mm (22deg) x 3M

Metal and Foam Back Channel ( Titania or Grey Friars)
Metal Back Channel Coro/Greca (GF) 45 x 20  x 20mm x 3.6M
Metal Back Channel Coro/Greca (T) 45 x 20  x 20mm x 3.6M
Metal Back Channel 5 Rib (GF) 45 x 35  x 35mm x 3.6M
Metal Back Channel 5 Rib (T) 45 x 35  x 35mm x 3.6M
Foam Back Channel Coro/Greca 20mm x 25mm x 3.6M
Foam Back Channel 5 Rib 38mm x 25mm x 3.6M

Polycarbonate Flat Sheet
Makrolon Flat sheet UV1 Clear 1.5mm x 1.2m x 6.0m
Makrolon Flat sheet UV1 Grey 1.2mm x 12.m x 6.0m
Makrolon Flat sheet UV1 Bronze 1.2mm x 12.m x 6.0m



Product Brochure
ALS013-Polycarbonate-Flashings-A4-WEB



Please note that we are a distributor and the product comes from Hamilton
Please allow 48hr for it to be delivered.
